一步一步实现扫雷游戏（C语言实现）(三)

使用WIN32API连接窗口

此项目相关博文链接

一步一步实现扫雷游戏（C语言实现）(一）

一步一步实现扫雷游戏（C语言实现）(二)

一步一步实现扫雷游戏（C语言实现）(三)

一步一步实现扫雷游戏（C语言实现）(四)

首先，我弄个主窗口出来，没有用到MFC，直接调用API函数实现，先看看代码吧：

///
//
//主函数：扫雷
//
///

#include <windows.h>
#include <stdio.h>
#include "DrawMap.h"//见下文
#include "def.h"

int m =10, n =10;
int map[MAX_X][MAX_Y];
int Global_x[MAX_X], Global_y[MAX_Y];


LRESULT CALLBACK WndProc (HWND, UINT, WPARAM, LPARAM) ;
WINGDIAPI BOOL WINAPI MoveToEx(HDC hdc, int x, int y, LPPOINT lppt);//移动当前画笔的位置
WINGDIAPI BOOL WINAPI LineTo(HDC hdc, int x, int y);//用来画直线的函数
WINGDIAPI HPEN WINAPI CreatePen(int iStyle, int cWidth, COLORREF color);




int WINAPI WinMain (HINSTANCE hInstance, HINSTANCE hPrevInstance,
 PSTR szCmdLine, int iCmdShow)
{
 init();//初始化数组（地雷分布
int x_position, y_position, x_size, y_size;
 set_position_size(&x_position, &y_position, &x_size, &y_size);

static TCHAR szAppName[] = TEXT ("MainWin") ;
 HWND hwnd ;
 MSG msg ;
 WNDCLASS wndclass ;

 wndclass.style = CS_HREDRAW | CS_VREDRAW ;
 wndclass.lpfnWndProc = WndProc ;
 wndclass.cbClsExtra =0 ;
 wndclass.cbWndExtra =0 ;
 wndclass.hInstance = hInstance ;
 wndclass.hIcon = LoadIcon (NULL, IDI_APPLICATION) ;
 wndclass.hCursor = LoadCursor (NULL, IDC_ARROW) ;
 wndclass.hbrBackground = (HBRUSH) GetStockObject (WHITE_BRUSH) ;
 wndclass.lpszMenuName = NULL ;
 wndclass.lpszClassName = szAppName ;

if (!RegisterClass (&wndclass))
 {
 MessageBox (NULL, TEXT ("This program requires Windows NT!"),
 szAppName, MB_ICONERROR) ;
return0 ;
 }

 hwnd = CreateWindow (szAppName, // window class name
 TEXT ("扫雷游戏——The ClearMines Game"), // window caption
 WS_OVERLAPPED | \
 WS_CAPTION | \
 WS_SYSMENU | \
 WS_MINIMIZEBOX, // window style
 x_position, // initial x position
 y_position, // initial y position
 x_size, // initial x size
 y_size, // initial y size
 NULL, // parent window handle
 NULL, // window menu handle
 hInstance, // program instance handle
 NULL) ; // creation parameters
 ShowWindow (hwnd, iCmdShow) ;
 UpdateWindow (hwnd) ;
while (GetMessage (&msg, NULL, 0, 0))
 {
 TranslateMessage (&msg) ;
 DispatchMessage (&msg) ;
 }
return msg.wParam ;
}

LRESULT CALLBACK WndProc (HWND hwnd, UINT message, WPARAM wParam, LPARAM lParam)
{
switch (message)
 {
case WM_PAINT:
 paint_map(hwnd); //自定义的画图函数
return0;

case WM_LBUTTONDOWN: //单击鼠标
int x=LOWORD(lParam);//x，y为鼠标当前的位置坐标
int y=HIWORD(lParam);
 left_key(hwnd, x, y);//自定义的响应鼠标左键的函数
break;

case WM_DESTROY:
 PostQuitMessage (0) ;
return0 ;
 }
return DefWindowProc (hwnd, message, wParam, lParam) ;
}

主窗口图：

现在，看看DrawMap.h文件的一些自定义函数的声明：

#include <windows.h>
#include <stdio.h>
#include "NumMines.h"//这个文件就是前两篇随笔中的那个后台实现算法的，等下也放上来

//全局变量
externint map[MAX_X][MAX_Y];
externint m, n;
externint Global_x[MAX_X], Global_y[MAX_Y];

//自定义函数
void paint_map(HWND hwnd);//又看到它了，那就看代码吧
BOOL DrawGrid(HDC hdc, int x1, int y1, int x2, int y2);//这个函数是实现在上面函数的
//设置窗口位置和大小
void set_position_size(int* p_x_position, int* p_y_position, int* p_x_size, int* p_y_size);
void left_key(HWND hwnd, int x, int y);
void DrawRec(HWND hwnd, HDC hdc, int i, int j);
RECT rectRec(HWND hwnd, int x, int y);//x,y为小矩形左上角的坐标

void paint_map(HWND hwnd);//又看到它了，那就看代码吧

//DrawMap.cpp


//
//画图
//

void paint_map(HWND hwnd)
{
 HDC hdc ;
 PAINTSTRUCT ps ;
 RECT rect ;
int x1,y1,x2,y2;
int x_position, y_position, x_size, y_size;
 set_position_size(&x_position, &y_position, &x_size, &y_size);

int frame_width = GetSystemMetrics(SM_CXSIZEFRAME); //边框宽度
int caption_width = GetSystemMetrics(SM_CYCAPTION); //标题栏宽度
int menu_high = GetSystemMetrics(SM_CYMENU); //菜单高度
 x1 = caption_width;
 y1 = caption_width;
 x2 = x_size - caption_width - frame_width;
 y2 = y_size -2*caption_width - frame_width;

 hdc = BeginPaint (hwnd, &ps) ;
 GetClientRect (hwnd, &rect) ;
 DrawGrid(hdc, x1, y1, x2, y2);
 EndPaint (hwnd, &ps) ;
}

///
//
//画格子
//
//
BOOL DrawGrid(HDC hdc, int x1, int y1, int x2, int y2)
{
int i, j;
 POINT ptLeftTop;
 BOOL tmp1, tmp2;
int tmp_x1;
int tmp_y1;
int tmp_x2;
int tmp_y2;

//画横线
 tmp_x1 = x1;
 tmp_y1 = y1;
 tmp_x2 = tmp_x1+((x2-x1)/m)*m;
for (i =0; i <= m; i++)
 {
if (i != m)
 {
 Global_y[i] = tmp_y1;
 }
 ptLeftTop.x = tmp_x1;
 ptLeftTop.y = tmp_y1;
 tmp1 = MoveToEx(hdc,ptLeftTop.x,ptLeftTop.y,NULL);
 ptLeftTop.x = tmp_x2;
 ptLeftTop.y = tmp_y1;
 tmp2 = LineTo(hdc,ptLeftTop.x,ptLeftTop.y);
 tmp_y1 += (y2-y1)/n;
 }

//画竖线
 tmp_x1 = x1;
 tmp_y1 = y1;
 tmp_y2 = tmp_y1+((y2-y1)/m)*m;
for (j =0; j <= n; j++)
 {
if (j != n)
 {
 Global_x[j] = tmp_x1;
 }
 ptLeftTop.x = tmp_x1;
 ptLeftTop.y = tmp_y1;
 tmp1 = MoveToEx(hdc,ptLeftTop.x,ptLeftTop.y,NULL);
 ptLeftTop.x = tmp_x1;
 ptLeftTop.y = tmp_y2;
 tmp2 = LineTo(hdc,ptLeftTop.x,ptLeftTop.y);
 tmp_x1 += (x2-x1)/m;
 }
if (tmp1 == FALSE || tmp2 == FALSE)
 {
return FALSE;
 }
return TRUE;
}



///
//
//响应左键事件
//这里有问题啊！！//单击鼠标左键不能再格子里画东西啊//求帮忙解答啊
//
void left_key(HWND hwnd, int x, int y)//x，y为鼠标当前的位置坐标
{
int tmp_x = x, tmp_y = y, i, j;
 POINT lpPoint;
 PAINTSTRUCT ps ;
 HDC hdc ;
 RECT rect ;

for (i =0; i < m-1; i++)
 {
if (tmp_x > Global_x[i] && tmp_x < Global_x[i+1]) break;
 }
for (j =0; j < n-1; j++)
 {
if (tmp_y > Global_y[j] && tmp_y < Global_y[j+1]) break;
 }

/***************************************************
 left ： 指定矩形框左上角的x坐标
 top： 指定矩形框左上角的y坐标
 right： 指定矩形框右下角的x坐标
　　bottom：指定矩形框右下角的y坐标
 ****************************************************/
 rect = rectRec(hwnd, tmp_x, tmp_y);
 hdc = GetDC(hwnd);
 COLORREF Minescolor = SetTextColor(hdc,RGB(255,0,0)); //设置地雷颜色
if (map[i][j] == MINES)
 {
 DrawText (hdc, TEXT ("*"), -1, &rect,
 DT_SINGLELINE | DT_CENTER | DT_VCENTER);
 GetClientRect(hwnd, &rect);
 DrawText (hdc, TEXT ("GAME OVER!"), -1, &rect,
 DT_SINGLELINE | DT_CENTER | DT_VCENTER);
 ReleaseDC(hwnd,hdc);
 MessageBox(hwnd, TEXT("再玩一次？"),TEXT("退出"), MB_RETRYCANCEL|MB_ICONQUESTION);
 }
elseif (map[i][j] ==0)
 {
//ReleaseDC(hwnd,hdc);
 DrawRec(hwnd, hdc, i, j);
 }
elseif (map[i][j] >0&& map[i][j] <9)
 {
 TCHAR str_tmp[10];
 sprintf(str_tmp,"%d",map[i][j]);
 DrawText (hdc, TEXT (str_tmp), -1, &rect,
 DT_SINGLELINE | DT_CENTER | DT_VCENTER);
//ReleaseDC(hwnd,hdc);
 }
}

//画0，表示该处为0个地雷 //感觉要使用递归，可就是无法实现
void DrawRec(HWND hwnd, HDC hdc, int i, int j)
{
 TCHAR str_tmp[1];
 RECT rect = rectRec(hwnd, Global_x[i], Global_y[j]); //当前小矩形的坐标

//hdc = GetDC(hwnd);
if (map[i][j] ==0)
 {
 sprintf(str_tmp,"%d",map[i][j]);
 DrawText (hdc, TEXT (str_tmp), -1, &rect,
 DT_SINGLELINE | DT_CENTER | DT_VCENTER) ;
 }
elseif (map[i][j] >0&& map[i][j] <9)
 {
 sprintf(str_tmp,"%d",map[i][j]);
 DrawText (hdc, TEXT (str_tmp), -1, &rect,
 DT_SINGLELINE | DT_CENTER | DT_VCENTER) ;
//ReleaseDC(hwnd,hdc);
return;
 }
}

////
//
//获取小矩形坐标
//
////
RECT rectRec(HWND hwnd, int l_x, int l_y)//x,y为小矩形左上角的坐标
{
 RECT rect;
int x1,y1,x2,y2;//窗口坐标
int x_position, y_position, x_size, y_size;
 set_position_size(&x_position, &y_position, &x_size, &y_size);

int frame_width = GetSystemMetrics(SM_CXSIZEFRAME); //边框宽度
int caption_width = GetSystemMetrics(SM_CYCAPTION); //标题栏宽度
int menu_high = GetSystemMetrics(SM_CYMENU); //菜单高度
 x1 = caption_width;
 y1 = caption_width;
 x2 = x_size - caption_width - frame_width;
 y2 = y_size -2*caption_width - frame_width;

 rect.left = l_x;
 rect.top = l_y;
 rect.right = l_x+((x2-x1)/m)*m;
 rect.bottom = l_y+((y2-y2)/m)*m;
return rect;
}

其他的代码也不上来：

//NumMines.h
#include <windows.h>

#include <stdio.h>
#include <string.h>
#include "time.h"
#include "stdlib.h"

#define MAX_X 100 //行坐标最大值
#define MAX_Y 100 //纵坐标最大值
#define MINES -1 //地雷

externint m, n;
externint map[MAX_X][MAX_Y];


void set_mines(int num_mines);
int round_num_mines(int i,int j);
BOOL init(void);

//NumMines.cpp

//NumMines.cpp

#include "NumMines.h"

#include <windows.h>

#include <stdio.h>
#include <string.h>
#include "time.h"
#include "stdlib.h"

/*******************************************************************
初始化地雷分布位置和个数
函数功能：根据设置的地雷个数和分布地图（map，数组）给出分布好了地雷的数组
函数原型：void set_mines( int num_mines)
参数：（in）—— int num_mines
*********************************************************************/
void set_mines(int num_mines)
{
int num =0;
int i,j;

while (num <= num_mines)
 {
 srand(time(0));
//rand()%n 取(0，n-1)的随机数
 i = rand() % m;
 j = rand() % n;
//如果出现相同的情况呢？，没事，再循环几次，直到有了足够的地雷为止
if (i<0|| i>m || j<0|| j>n || map[i][j] == MINES)
 {
continue;
 }
 map[i][j] = MINES;
 num++;//判断地雷个数
 }
}

/****************************************************************************
返回周围地雷个数的函数
函数原型： int round_num_mines(int i,int j);
 参 数： int i, int j为当前的坐标
返回值类型： int 返回该坐标处周围的地雷数
返回值情况：（1）返回1-8代表周围有1-8个地雷；
 （2）返回0代表周围没有地雷；
 （3）返回*代表此坐标时地雷；
******************************************************************************/
int round_num_mines(int i,int j)
{
if (map[i][j] == MINES)
 {
return MINES;
 }

int dir[8][2] = {{-1,-1},{-1,0},{-1,1},{0,1},{1,1},{1,0},{1,-1},{0,-1}};
int k =0, num_mines =0;

for (k =0; k <8; k++)
 {
if (map[i+dir[k][0]][j+dir[k][1]] =='*')
 {
 num_mines++;
 }
 }
return num_mines;
}

BOOL init(void)
{
 memset(map, 0, sizeof(map));
int i, j;
int flag =0;

 set_mines((m*n)/10);//55个地雷

for (i=0; i<m; i++)
 {
for (j=0; j<=n; j++)
 {
 map[i][j] = round_num_mines(i, j);
 flag =1;
 }
 }
if (1== flag)
 {
return TRUE;
 }
return FALSE;
}

//DEF.H


#ifndef _DEF_
#define _DEF_

#define MAX_X 100 //行坐标最大值
#define MAX_Y 100 //纵坐标最大值
#define MINES -1 //地雷
#define DEF_M //默认行坐标
#define DEF_N //默认列坐标

#endif /* _DEF_ */

希望朋友们知道的帮忙解答解答，谢谢
